Labs

The Chair of Process Control Engineering operates a number of laboratories and experimental setups that are used in projects and are also available for research partners.  A brief description and corresponding links on pages with detailed information can be found below.

Process-to-Order Lab

© Urbas

The Process-To-Order Lab is used to advance current research topics in the areas of digitization and modularization of the process industry.

Engineering-Labor

© PLT 2014

The Engineering-Labor houses the modular continuous plant and the batch plant as well as two teaching and research facilities for the process industry. In addition, there are the corresponding engineering stations and control rooms.

Usability for Process Industry (UPI) Lab

© PLT 2014

The UPI-Labor offers the opportunity to perform usability studies of stationary and mobile devices in a controlled environment. In addition, experiments can be carried out and documented in an industrial environment.

Our Labs and Equipment on the Technology Portal

A list of our equipment is availabe on the Dresden Technology Portal.

M04 BioReactor-Module

Manufacturer: P2O-Lab

Example Process Equipment Assembly (PEA) for biochemical reactions of liquid medium with automated services following the standard of the VDI/VDE/NAMUR 2658 (Module Type Package, MTP).

To the instrument

M02 Reactor-PEA

Manufacturer: P2O-Lab

Example Process Equipment Assembly (PEA) with automated services following the standard of the VDI/VDE/NAMUR 2658 (Module Type Package, MTP).

To the instrument

© © PLT

Modular Plant (MOKA)

The modular continuous plant is a research environment for the demonstration and verification of concepts and strategies which shall simplify the integration of modules into the control system.

To the instrument

PCS Engineering Lab

At the engineering-lab, one can plan and construct process plant from basic engineering to detail-engineering and program from simulation to the commissioning.

To the instrument

© © PLT

Multi-product multi-path experimental batch plant

The heart of the plant are two reactor, within different products can be produced simultaneously. The plant can be classified as a multi-product and multi-strand returnable system.

To the instrument

© TUD/P2O

M01 Dosing-PEA

Manufacturer: P2O-Lab

Example Process Equipment Assembly (PEA) for storage and dosing of liquid medium with automated services following the standard of the VDI/VDE/NAMUR 2658 (Module Type Package, MTP).

To the instrument

© © PLT

Usability for Process Industries (UPI) Lab

Manufacturer: Mangold

The UPI laboratory provides the possibility to study the daily usability of stationary and mobile devices within a controlled environment.

To the instrument

Smart Scale Modularization plant

The Smart Scale Modularization (SSM) plant is currently under reconstruction. It serves as an industrial-scale plant which can be used to apply new process control concepts or evaluate…

To the instrument

This information is provided by the Dresden Technology Portal.
