Weaving Machines

• Manufacturer of the loom:  Mageba Textilmaschinen GmbH & Co. KG
• Weft insertion system: shuttles combined with rapier rods (MAGEBA shuttle rapier system)
• Manufacturer jacquard: Stäubli GmbH
• Maximum fabric width:      1.000 mm
• Jacquard:  electronically controlled jacquard unit for 3072 heddles/m with three-position shed
• Number of weaving systems:  4
• Linear reed movement

• Fll 4 shuttle rapier system are freely programmable (in selection and lift)
• Freely adjustable weaving width up to 1000 mm
• Suitable for the manufacturing of mult-layered , tubular and spacer fabrics as well as profile or 3D structures and special fabrics
• Solid design of all relevant machine components enables processing of coarse yarns, in particular for composites

• Manufacturer: Lindauer DORNIER GmbH
• Nominal width 190 cm
• Patterning across 20 heald frames, electronically controlled, ORW (OpenReedWeaving) technology
• Four-color weftpatterning
• Electronically controlled weft change device
• 4 warp let-off points, electronic
• Electronically controlled fabric take-off

• DORNIER OpenReedWeaving-technology for the weave-technical integration of several multiaxial yarn systems
• Up to 4 warp beams
• Suitable for the processing of carbon

Supported by Lindauer DORNIER GmbH

• Manufacturer: Lindauer DORNIER GmbH
• Fabric width range: 100 to 180 cm
• One needle bar unit, maximum of 30 threads per cm
• Fill pattern with 4- color electronically controlled weft changers
• Schussmusterung über 4-Farben Schusswechsler elektronisch gesteuert
• 2 warp release gears
• EasyLeno^® 2T
• Electronically controlled fabric wind-up

• Rapier weaving machine for the production of leno weaves
• Machine is equipped to process glass and carbon yarns




• Weaving machine manufacturer: Lindauer DORNIER GmbH
• Jacquard machine manufacturer: Stäubli GmbH
• Fabric width range: 100 to 140 cm
• 6144 hooks

• Full Jacquard across complete working width
• Heddle movement and timing independently controlled for each weft
• Processing of low-elongation materials like carbon, glass or aramide yarns
• Development of bonding-technically modified technical textiles and pre-woven pre-products

• Manufacturer: NV Michael Van de Wiele
• Fabric width range: 100 to 160 cm
• Spacer fabrics of 0 to 30 mm spacings
• 4 pile heald frames, 8 ground heald frames, 4 bracket heald frames, electronically controlled
• Jacquard unit for 2,000 pole yarns
• 4-color weft control for both weft systems
• 2 ground warp let-off points
• 2 pile warp let-off points with supply units

• Double-rapier weaving machine for the production of multilayered and spacer fabrics
• Extra equipment: pleat weaving unit

• Narrow fabric shuttle weaving machine manufacturer: Mageba Textilmaschinen GmbH & Co. KG
• Jacquard machine manufacturer: Stäubli GmbH
• Fabric width range: up to 150 mm
• Dobby with 16 heald frames
• Jacquard machine LX 32 with 448 hooks
• All functions, shed formation, weft insertion and beat-up with linear reed motion and fabric take-off are controlled servo-electronically

• Suitable for the production of special fabrics, multilayered fabrics, tubes and profiles for composite materials

• Manufacturer: Jakob Müller AG, Switzerland
• Fabric width range: up to 130 mm
• Electronic dobby with 8 pile heald frames (4 shed positions) and 12 ground heald frames
• Up to three warp needles (three ply)

• Narrow fabric weaving machine for single-ply and multilayered narrow fabrics
• Extra equipment: pleat weaving unit
